Xceed Toolkit Plus for WPF v5.0 Documentation
Xceed.Wpf.Toolkit Assembly / Xceed.Wpf.Toolkit.Zoombox Namespace / Zoombox Class
Members


In This Topic
    Zoombox Class
    In This Topic
     Defines an area with zoom and pan functionality for its contents.
    Syntax
    'Declaration

    <TemplatePartAttribute(Name="PART_VerticalScrollBar", Type=System.Windows.Controls.Primitives.ScrollBar)>
    <DefaultPropertyAttribute("Content")>
    <ContentPropertyAttribute("Content")>
    <LocalizabilityAttribute(LocalizationCategory.None, Readability=Readability.Unreadable)>
    <StyleTypedPropertyAttribute(Property="FocusVisualStyle", StyleTargetType=System.Windows.Controls.Control)>
    <XmlLangPropertyAttribute("Language")>
    <UsableDuringInitializationAttribute(True)>
    <RuntimeNamePropertyAttribute("Name")>
    <UidPropertyAttribute("Uid")>
    <TypeDescriptionProviderAttribute(MS.Internal.ComponentModel.DependencyObjectProvider)>
    <NameScopePropertyAttribute("NameScope", System.Windows.NameScope)>
    Public NotInheritable Class Zoombox
       Inherits System.Windows.Controls.ContentControl
    'Usage

    Dim instance As Zoombox
    [TemplatePart(Name="PART_VerticalScrollBar", Type=System.Windows.Controls.Primitives.ScrollBar)]
    [DefaultProperty("Content")]
    [ContentProperty("Content")]
    [Localizability(LocalizationCategory.None, Readability=Readability.Unreadable)]
    [StyleTypedProperty(Property="FocusVisualStyle", StyleTargetType=System.Windows.Controls.Control)]
    [XmlLangProperty("Language")]
    [UsableDuringInitialization(true)]
    [RuntimeNameProperty("Name")]
    [UidProperty("Uid")]
    [TypeDescriptionProvider(MS.Internal.ComponentModel.DependencyObjectProvider)]
    [NameScopeProperty("NameScope", System.Windows.NameScope)]
    public sealed class Zoombox : System.Windows.Controls.ContentControl
    Remarks
    The Zoombox control provides zoom and pan functionality for its content. It also provides ViewFinder functionality so that the user can identify where they are viewing within the bigger picture. Finally, it provides a view stack and various navigation methods so that the user can navigate back or forward through previous views or zoom to common views.
    Inheritance Hierarchy

    System.Object
       System.Windows.Threading.DispatcherObject
          System.Windows.DependencyObject
             System.Windows.Media.Visual
                System.Windows.UIElement
                   System.Windows.FrameworkElement
                      System.Windows.Controls.Control
                         System.Windows.Controls.ContentControl
                            Xceed.Wpf.Toolkit.Zoombox.Zoombox

    Requirements

    Target Platforms: Windows 11, Windows 10, Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2
