PerspectivePanel Class

The panel will lay out every element in a Perspective manner, Each subsequent item size will be scaled down The decay of size can be specified as a DP.

Syntax

Visual Basic
C#

'Declaration

<LocalizabilityAttribute(LocalizationCategory.Ignore)>

<ContentPropertyAttribute("Children")>

<StyleTypedPropertyAttribute(Property="FocusVisualStyle", StyleTargetType=System.Windows.Controls.Control)>

<XmlLangPropertyAttribute("Language")>

<UsableDuringInitializationAttribute(True)>

<RuntimeNamePropertyAttribute("Name")>

<UidPropertyAttribute("Uid")>

<TypeDescriptionProviderAttribute(MS.Internal.ComponentModel.DependencyObjectProvider)>

<NameScopePropertyAttribute("NameScope", System.Windows.NameScope)>

Public Class PerspectivePanel

   Inherits AnimationPanel

'Usage

Dim instance As PerspectivePanel

[Localizability(LocalizationCategory.Ignore)]

[ContentProperty("Children")]

[StyleTypedProperty(Property="FocusVisualStyle", StyleTargetType=System.Windows.Controls.Control)]

[XmlLangProperty("Language")]

[UsableDuringInitialization(true)]

[RuntimeNameProperty("Name")]

[UidProperty("Uid")]

[TypeDescriptionProvider(MS.Internal.ComponentModel.DependencyObjectProvider)]

[NameScopeProperty("NameScope", System.Windows.NameScope)]

public class PerspectivePanel : AnimationPanel

Example

XAML

<Window x:Class="PerspectivePanelSample.MainWindow"

        xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"

        xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"

        xmlns:xctk="http://schemas.xceed.com/wpf/xaml/toolkit"

        Title="PerspectivePanelSample">

  <Grid>

    <xctk:PerspectivePanel AnchorX="250"

                          AnchorY="50"

                          ShiftX="150"

                          ShiftY="70"

                          AngleOfTwist="-10"

                          DecayConstant="0.2">

      <Button Content="First" />

      <Button Content="Second" />

      <Button Content="Third" />

    </xctk:PerspectivePanel>

  </Grid>

</Window>

Inheritance Hierarchy

System.Object
   System.Windows.Threading.DispatcherObject
      System.Windows.DependencyObject
         System.Windows.Media.Visual
            System.Windows.UIElement
               System.Windows.FrameworkElement
                  System.Windows.Controls.Panel
                     Xceed.Wpf.Toolkit.Panels.PanelBase
                        Xceed.Wpf.Toolkit.Panels.AnimationPanel
                           Xceed.Wpf.Toolkit.Panels.PerspectivePanel

Requirements

Target Platforms: Windows 11, Windows 10, Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2

Reference

PerspectivePanel Members
Xceed.Wpf.Toolkit.Panels Namespace
