Xceed Toolkit Plus for WPF v5.0 Documentation
Xceed.Wpf.Toolkit Assembly / Xceed.Wpf.Toolkit.Panels Namespace / SwitchPanel Class
Members Example


In This Topic
    SwitchPanel Class
    In This Topic
    Allows you to switch between panels with the same children on the fly with animation support.
    Syntax
    'Declaration

    <LocalizabilityAttribute(LocalizationCategory.Ignore)>
    <ContentPropertyAttribute("Children")>
    <StyleTypedPropertyAttribute(Property="FocusVisualStyle", StyleTargetType=System.Windows.Controls.Control)>
    <XmlLangPropertyAttribute("Language")>
    <UsableDuringInitializationAttribute(True)>
    <RuntimeNamePropertyAttribute("Name")>
    <UidPropertyAttribute("Uid")>
    <TypeDescriptionProviderAttribute(MS.Internal.ComponentModel.DependencyObjectProvider)>
    <NameScopePropertyAttribute("NameScope", System.Windows.NameScope)>
    Public Class SwitchPanel
       Inherits PanelBase
    'Usage

    Dim instance As SwitchPanel
    [Localizability(LocalizationCategory.Ignore)]
    [ContentProperty("Children")]
    [StyleTypedProperty(Property="FocusVisualStyle", StyleTargetType=System.Windows.Controls.Control)]
    [XmlLangProperty("Language")]
    [UsableDuringInitialization(true)]
    [RuntimeNameProperty("Name")]
    [UidProperty("Uid")]
    [TypeDescriptionProvider(MS.Internal.ComponentModel.DependencyObjectProvider)]
    [NameScopeProperty("NameScope", System.Windows.NameScope)]
    public class SwitchPanel : PanelBase
    Example
    A SwitchPanel example. You change the current layout by setting ActiveLayoutIndex property to a new value.
    <Window x:Class="SwitchPanelSample.MainWindow"
            xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
            xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
            xmlns:xctk="http://schemas.xceed.com/wpf/xaml/toolkit"
            Title="SwitchPanelSample">
      <Grid>
        <xctk:SwitchPanel>
          <xctk:SwitchPanel.Layouts>
            <xctk:AutoStretchStackPanel Orientation="Horizontal" />
            <xctk:AutoStretchStackPanel Orientation="Vertical" />
            <xctk:Canvas />
            <xctk:RadialCanvas />
            <xctk:RandomPanel MinimumHeight="80"
                                    MaximumHeight="300"
                                    MaximumWidth="400"
                                    MinimumWidth="80" />
            <xctk:StackPanel Orientation="Horizontal"
                                  Width="200" />
            <xctk:StackPanel Orientation="Vertical" />
            <xctk:WrapPanel Orientation="Horizontal" />
            <xctk:WrapPanel Orientation="Vertical" />
          </xctk:SwitchPanel.Layouts>
          <Rectangle Margin="2, 2, 2, 2"
                    Width="300"
                    Height="300"
                    Fill="Red" />
          <Rectangle Margin="2, 2, 2, 2"
                    Width="300"
                    Height="300"
                    Fill="Blue" />
          <Rectangle Margin="2, 2, 2, 2"
                    Width="300"
                    Height="300"
                    Fill="Green" />
          <Rectangle Margin="2, 2, 2, 2"
                    Width="300"
                    Height="300"
                    Fill="Orange" />
          <Rectangle Margin="2, 2, 2, 2"
                    Width="300"
                    Height="300"
                    Fill="Purple" />
          <Rectangle Margin="2, 2, 2, 2"
                    Width="300"
                    Height="300"
                    Fill="Yellow" />
        </xctk:SwitchPanel>
      </Grid>
    </Window>
    Inheritance Hierarchy

    System.Object
       System.Windows.Threading.DispatcherObject
          System.Windows.DependencyObject
             System.Windows.Media.Visual
                System.Windows.UIElement
                   System.Windows.FrameworkElement
                      System.Windows.Controls.Panel
                         Xceed.Wpf.Toolkit.Panels.PanelBase
                            Xceed.Wpf.Toolkit.Panels.SwitchPanel

    Requirements

    Target Platforms: Windows 11, Windows 10, Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2
