    RandomPanel Class
    In This Topic
    This panel layouts out its children with a random location and size.
    Syntax
    'Declaration

    <LocalizabilityAttribute(LocalizationCategory.Ignore)>
    <ContentPropertyAttribute("Children")>
    <StyleTypedPropertyAttribute(Property="FocusVisualStyle", StyleTargetType=System.Windows.Controls.Control)>
    <XmlLangPropertyAttribute("Language")>
    <UsableDuringInitializationAttribute(True)>
    <RuntimeNamePropertyAttribute("Name")>
    <UidPropertyAttribute("Uid")>
    <TypeDescriptionProviderAttribute(MS.Internal.ComponentModel.DependencyObjectProvider)>
    <NameScopePropertyAttribute("NameScope", System.Windows.NameScope)>
    Public Class RandomPanel
       Inherits AnimationPanel
    'Usage

    Dim instance As RandomPanel
    [Localizability(LocalizationCategory.Ignore)]
    [ContentProperty("Children")]
    [StyleTypedProperty(Property="FocusVisualStyle", StyleTargetType=System.Windows.Controls.Control)]
    [XmlLangProperty("Language")]
    [UsableDuringInitialization(true)]
    [RuntimeNameProperty("Name")]
    [UidProperty("Uid")]
    [TypeDescriptionProvider(MS.Internal.ComponentModel.DependencyObjectProvider)]
    [NameScopeProperty("NameScope", System.Windows.NameScope)]
    public class RandomPanel : AnimationPanel
    Example
    A RandomPanel example. The random size of child is contrained within the MinimumHeight, MaximumHeight, MinimumWidth, and MaximumWidth values.
    <Page x:Class="RandomPanelSample.Sample"
      xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
      xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
      xmlns:blendables="http://schemas.xceed.com/wpf/xaml/blendables"
      Title="RandomPanelSample">
      <Grid>
        <blendables:RandomPanel MinimumHeight="80" MaximumHeight="300" MaximumWidth="400" MinimumWidth="80">
          <Rectangle Fill="Green"/>
          <Rectangle Fill="Red"/>
          <Rectangle Fill="Blue"/>
          <Rectangle Fill="Orange"/>
          <Rectangle Fill="Yellow"/>
        </blendables:RandomPanel>
      </Grid>
    </Page>
    Inheritance Hierarchy

    System.Object
       System.Windows.Threading.DispatcherObject
          System.Windows.DependencyObject
             System.Windows.Media.Visual
                System.Windows.UIElement
                   System.Windows.FrameworkElement
                      System.Windows.Controls.Panel
                         Xceed.Wpf.Toolkit.Panels.PanelBase
                            Xceed.Wpf.Toolkit.Panels.AnimationPanel
                               Xceed.Wpf.Toolkit.Panels.RandomPanel

    Requirements

    Target Platforms: Windows 11, Windows 10, Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2

    See Also
