    PerspectivePanel Class
    In This Topic
    The panel will lay out every element in a Perspective manner, Each subsequent item size will be scaled down The decay of size can be specified as a DP.
    Syntax
    'Declaration

    <LocalizabilityAttribute(LocalizationCategory.Ignore)>
    <ContentPropertyAttribute("Children")>
    <StyleTypedPropertyAttribute(Property="FocusVisualStyle", StyleTargetType=System.Windows.Controls.Control)>
    <XmlLangPropertyAttribute("Language")>
    <UsableDuringInitializationAttribute(True)>
    <RuntimeNamePropertyAttribute("Name")>
    <UidPropertyAttribute("Uid")>
    <TypeDescriptionProviderAttribute(MS.Internal.ComponentModel.DependencyObjectProvider)>
    <NameScopePropertyAttribute("NameScope", System.Windows.NameScope)>
    Public Class PerspectivePanel
       Inherits AnimationPanel
    'Usage

    Dim instance As PerspectivePanel
    [Localizability(LocalizationCategory.Ignore)]
    [ContentProperty("Children")]
    [StyleTypedProperty(Property="FocusVisualStyle", StyleTargetType=System.Windows.Controls.Control)]
    [XmlLangProperty("Language")]
    [UsableDuringInitialization(true)]
    [RuntimeNameProperty("Name")]
    [UidProperty("Uid")]
    [TypeDescriptionProvider(MS.Internal.ComponentModel.DependencyObjectProvider)]
    [NameScopeProperty("NameScope", System.Windows.NameScope)]
    public class PerspectivePanel : AnimationPanel
    Example
    <Window x:Class="PerspectivePanelSample.MainWindow"
            xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
            xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
            xmlns:xctk="http://schemas.xceed.com/wpf/xaml/toolkit"
            Title="PerspectivePanelSample">
      <Grid>
        <xctk:PerspectivePanel AnchorX="250"
                              AnchorY="50"
                              ShiftX="150"
                              ShiftY="70"
                              AngleOfTwist="-10"
                              DecayConstant="0.2">
          <Button Content="First" />
          <Button Content="Second" />
          <Button Content="Third" />
        </xctk:PerspectivePanel>
      </Grid>
    </Window>
    Inheritance Hierarchy

    System.Object
       System.Windows.Threading.DispatcherObject
          System.Windows.DependencyObject
             System.Windows.Media.Visual
                System.Windows.UIElement
                   System.Windows.FrameworkElement
                      System.Windows.Controls.Panel
                         Xceed.Wpf.Toolkit.Panels.PanelBase
                            Xceed.Wpf.Toolkit.Panels.AnimationPanel
                               Xceed.Wpf.Toolkit.Panels.PerspectivePanel

    Requirements

    Target Platforms: Windows 11, Windows 10, Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2
